Digital stainless steel flow meter operate under the principle of Faraday's Law of Electromagnetic Induction to measure liquid velocity. Digital flow meters is applicable for all food grade conductive liquids measure, such as drinking water, food processing, pharmaceutical industry and many others. Typical applications are monitoring accurate measurements in liquid, metering and custody transfer
TECHNICAL DATA
Nominal Diameter DN6-DN3000mmFlow DirectionTwo-way measurementRepeatability Error±0.1%Accuracy±0.5%FSMedium Conductivity≥20μs/cmRelative humidity5％-90％Connection typeFlange/Thread/Tri-clamp connectionSignal output4-20mA, Pulse, RS485 Modbus, Hart, Profibus etc.Power supplyDC24V (20-36V)AC220V (85-250V)3.6V battery poweredLining materialCR: -25-+80℃(Weak wear medium)PU: -25-+80℃ (Strong resistance to wear and tear)PTFE: -25-+120℃ (Corrosion resistant)FPM: -25-+180℃ (High temperature resistant)F46: -25-+ 180℃ (Corrosion resistance; Resistant to high and negative pressure)PFA: -25-+ 180℃ (Corrosion resistance; Resistant to high and negative pressure)Electrode material316L (No corrosion/weak corrosion)HB (Resistant to non-oxidizing acid, alkali and salt)HC (Oxidation-resistant acid, alkali and salt)Ti (Chloride, Hypochlorite, oxidizing acid)Ta (Strong corrosion resistance)Pt (Apply to almost all chemicals except aqua regia and ammonium salts)Nominal PressureDN50≤M4.0MpaDN65-DN250≤l.6MpaDN300-DN1000≤1.0MpaDN1200-DN3000≤0.6MpaOr other specified by orderProtection GradeIntegral type: IP65 Split type: sensor IP68, transducer IP65product applicationWidely used in petroleum, chemical, metallurgy, light textile, paper making, environmental protection, food and other industrial departments and municipal management, water conservancy construction, river dredging and other fields of flow measurement
